2-5/8 Pro-Comp

OVERVIEW

When you are pushing your air-cooled Volkswagen to the limit, whether it is on the drag strip, navigating a rocky trail in a rail, or cruising the coast in a vintage Beetle, monitoring your engine''s vitals is not just a luxuryit is a necessity. The AutoMeter 2-5/8 inch Pro-Comp Oil Pressure Gauge (ATM5437) represents the gold standard in analog monitoring. Designed with a rugged air core meter movement, this electric gauge provides the rapid response and dead-on accuracy that professional racers demand, while maintaining the classic look that fits perfectly in a custom VW dash. Unlike smaller, harder-to-read gauges, the 2-5/8 inch diameter offers superior visibility at a glance, ensuring you know exactly what your oil pressure is doing before a minor fluctuation becomes a catastrophic engine failure. This is especially critical for high-performance air-cooled builds where oil is the primary cooling agent and consistent pressure is the only thing standing between you and a spun bearing.

The Pro-Comp series from AutoMeter is legendary in the automotive world for its durability and distinct aesthetic. This specific gauge features a crisp black face, high-contrast white numbering, and the iconic red pointer that has become synonymous with performance. The silver bezel provides a clean, professional finish that complements both modern aluminum dash panels and vintage-style interiors. One of the standout features of the Pro-Comp electric line is that it is engineered to match the appearance of liquid-filled mechanical gauges, giving you that hardcore racing look without the need to run high-pressure oil lines directly into your cabin. It is a seamless blend of old-school style and modern electrical precision, making it a top-tier choice for any Volkswagen enthusiast who refuses to compromise on quality or safety. At Appletree Auto, we know that your VW is more than just a car; it is an investment in time and passion, and this AutoMeter gauge is the best insurance policy you can buy for your engine.

FITMENT

• Volkswagen Type 1 Beetle: All years and models (Custom dash mounting required).
• Volkswagen Type 2 Bus / Transporter: 1950 through 1979 (Ideal for overhead or dash pods).
• Volkswagen Type 3 (Squareback, Fastback, Notchback): 1961 through 1973.
• Volkswagen Karmann Ghia: All years.
• Volkswagen Thing (Type 181): All years.
• Dune Buggies & Sand Rails: All custom fiberglass or tube chassis applications.
• Meyers Manx & Clones: Perfect for center-mounted gauge pods.
• Trikes & Custom Air-Cooled Builds: Universal 12V application for any Type 1, Type 2, or Type 4 engine case.

SPECS

• Product Line: AutoMeter Pro-Comp Series.
• Gauge Diameter: 2-5/8 inches (66.7mm).
• Gauge Type: Electric (Short Sweep).
• Pressure Range: 0 to 100 PSI.
• Movement Type: Rugged Air Core.
• Bezel Finish: Silver / Brushed Aluminum Style.
• Face Color: Black with White Numbers.
• Pointer Color: Red.
• Lighting: Incandescent (Around-the-dial).
• Voltage: 12 Volt DC operation.
• Sender Included: Yes, 1/8 inch NPT Electric Sending Unit.
• Adapter Fittings: Includes 1/4 inch NPT adapter.

PRO TIPS

1. Ensure a Perfect Ground for Accuracy

Electric gauges are highly sensitive to resistance in the wiring. In an air-cooled VW, especially those with fiberglass bodies like a Dune Buggy or a Meyers Manx, the lack of a metal chassis can cause grounding issues. Always run a dedicated ground wire from the gauge directly to the engine block or a solid chassis ground point. If your sender is mounted to a relocation block, ensure that block is also properly grounded. A poor ground can cause the needle to jump or provide "lazy" readings, which could lead you to believe your oil pressure is lower or higher than it actually is. Double-checking your connections during the initial install prevents headaches later on the trail.

2. Use an Oil Pressure Sender Relocation Kit

While the 1/8 inch NPT sender included with the ATM5437 is high-quality, mounting it directly into the VW engine case near the distributor can be a tight squeeze, especially if you have a high-performance upright fan shroud or dual carburetors. I highly recommend using a stainless steel braided hose relocation kit. This allows you to mount the sender away from the heat of the engine and reduces the vibration the sender is exposed to. Furthermore, using a "T-fitting" with a relocation kit allows you to keep your stock oil pressure "dummy light" switch functional, providing you with both a visual gauge for monitoring and a bright warning light for immediate alerts.

3. Plan Your Dash Layout for the 2-5/8 Size

Keep in mind that this is the larger 2-5/8 inch gauge, not the standard 2-1/16 inch size. This makes it significantly easier to read while driving at high speeds or in off-road conditions where the car is bouncing. However, it does require a larger hole in your dash or a specific 2-5/8 inch mounting cup. If you are building a custom panel, I suggest mocking it up with a template first. The larger size looks incredible and "period correct" for 1970s and 80s race-inspired builds, but you want to ensure you have enough clearance behind the dash for the wiring harness and the mounting bracket before you start cutting your holes.
